Robocode Tank AI实例

最近公司流行玩Robocode,这是一个坦克机器人战斗仿真引擎,里面可以写一些自己的Tank来互相战斗。
主要是使用了躲避子弹和避墙的思想
package azrael;
import robocode.*;
//import java.awt.Color;
// API help : http://robocode.sourceforge.net/docs/robocode/robocode/Robot.html
/**
* Aldis - a robot by (your name here)
*/
public class Aldis extends AdvancedRobot {
double previousEnergy = 100;
int movementDirection = 1;
int gunDirection = 1;
int direction = 1;
/**
* run: Aldis's default behavior
*/
public void run() {
while (true) {
setTurnRightRadiansOptimal(adjustHeadingForWalls(0));
setAhead(100);
execute();
}
}
private static final double DOUBLE_PI = (Math.PI * 2);
private static final double HALF_PI = (Math.PI / 2);
private static final double WALL_AVOID_INTERVAL = 10;
private static final double WALL_AVOID_FACTORS = 20;
private static final double WALL_AVOID_DISTANCE = (WALL_AVOID_INTERVAL * WALL_AVOID_FACTORS);
public double calculateBearingToXYRadians(double sourceX, double sourceY,
double sourceHeading, double targetX, double targetY) {
return normalizeRelativeAngleRadians(
Math.atan2((targetX - sourceX), (targetY - sourceY)) -
sourceHeading);
}
public double normalizeAbsoluteAngleRadians(double angle) {
if (angle < 0) {
return (DOUBLE_PI + (angle % DOUBLE_PI));
} else {
return (angle % DOUBLE_PI);
}
}
public static double normalizeRelativeAngleRadians(double angle) {
double trimmedAngle = (angle % DOUBLE_PI);
if (trimmedAngle > Math.PI) {
return -(Math.PI - (trimmedAngle % Math.PI));
} else if (trimmedAngle < -Math.PI) {
return (Math.PI + (trimmedAngle % Math.PI));
} else {
return trimmedAngle;
}
}
private double adjustHeadingForWalls(double heading) {
double fieldHeight = getBattleFieldHeight();
double fieldWidth = getBattleFieldWidth();
double centerX = (fieldWidth / 2);
double centerY = (fieldHeight / 2);
double currentHeading = getRelativeHeadingRadians();
double x = getX();
double y = getY();
boolean nearWall = false;
double desiredX;
double desiredY;
// If we are too close to a wall, calculate a course toward
// the center of the battlefield.
if ((y < WALL_AVOID_DISTANCE)
|| ((fieldHeight - y) < WALL_AVOID_DISTANCE)) {
desiredY = centerY;
nearWall = true;
} else {
desiredY = y;
}
if ((x < WALL_AVOID_DISTANCE)
|| ((fieldWidth - x) < WALL_AVOID_DISTANCE)) {
desiredX = centerX;
nearWall = true;
} else {
desiredX = x;
}
// Determine the safe heading and factor it in with the desired
// heading if the bot is near a wall
if (nearWall) {
double desiredBearing = calculateBearingToXYRadians(x, y,
currentHeading, desiredX, desiredY);
double distanceToWall = Math.min(Math.min(x, (fieldWidth - x)),
Math.min(y, (fieldHeight - y)));
int wallFactor = (int) Math.min(
(distanceToWall / WALL_AVOID_INTERVAL), WALL_AVOID_FACTORS);
return ((((WALL_AVOID_FACTORS - wallFactor) * desiredBearing) + (wallFactor * heading)) / WALL_AVOID_FACTORS);
} else {
return heading;
}
}
public double getRelativeHeadingRadians() {
double relativeHeading = getHeadingRadians();
if (direction < 1) {
relativeHeading = normalizeAbsoluteAngleRadians(relativeHeading
+ Math.PI);
}
return relativeHeading;
}
public void reverseDirection() {
double distance = (getDistanceRemaining() * direction);
direction *= -1;
setAhead(distance);
}
public void setAhead(double distance) {
double relativeDistance = (distance * direction);
super.setAhead(relativeDistance);
if (distance < 0) {
direction *= -1;
}
}
public void setBack(double distance) {
double relativeDistance = (distance * direction);
super.setBack(relativeDistance);
if (distance > 0) {
direction *= -1;
}
}
public void setTurnLeftRadiansOptimal(double angle) {
double turn = normalizeRelativeAngleRadians(angle);
if (Math.abs(turn) > HALF_PI) {
reverseDirection();
if (turn < 0) {
turn = (HALF_PI + (turn % HALF_PI));
} else if (turn > 0) {
turn = -(HALF_PI - (turn % HALF_PI));
}
}
setTurnLeftRadians(turn);
}
public void setTurnRightRadiansOptimal(double angle) {
double turn = normalizeRelativeAngleRadians(angle);
if (Math.abs(turn) > HALF_PI) {
reverseDirection();
if (turn < 0) {
turn = (HALF_PI + (turn % HALF_PI));
} else if (turn > 0) {
turn = -(HALF_PI - (turn % HALF_PI));
}
}
setTurnRightRadians(turn);
}
/**
* onScannedRobot: What to do when you see another robot
*/
public void onScannedRobot(ScannedRobotEvent e) {
// Stay at right angles to the opponent
fire(2);
setTurnRight(e.getBearing() + 90 - 30 * movementDirection);
// If the bot has small energy drop,
// assume it fired
double changeInEnergy = previousEnergy - e.getEnergy();
if (changeInEnergy > 0 && changeInEnergy <= 3) {
// Dodge!
movementDirection = -movementDirection;
setAhead((e.getDistance() / 4 + 25) * movementDirection);
}
// When a bot is spotted,
// sweep the gun and radar
gunDirection = -gunDirection;
setTurnGunRight(99999 * gunDirection);
// Fire directly at target
// fire( 2 ) ;
// Track the energy level
previousEnergy = e.getEnergy();
}
}
